SCE210 Series
Stainless Steel Enclosure for 1 to 4 CTC Signal Conditioners, NEMA 4X (IP66) Rated
Product Features
Provides 4-20 mA Signals along with dynamic outputs from remotely installed accelerometers to PLC/DCS systems and portable data collectors
Accommodates up to 4 CTC Signal Conditioners factory wired to power supply
- Accepts up to 4 single output sensor inputs for a maximum of 4 channels of measurement
- Includes DC Power Supply with 100-240 VAC Input
- Signal conditioners sold separately
| Specifications | |
|---|---|
| Temperature Range | 15 to 140 °F (-10 to 60 °C) |
| Enclosure Material | Stainless Steel |
| Power | 100-240 VAC |
| Inputs | Vibration Input: 1 Input/Channel |
| Outputs | BNC Jack for Dynamic Signal and Screw Terminal Blocks for 4-20 mA Outputs |
| Sensor Input Options | 1 - 4 Channels |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Lock |
| Dimensions | 10.00 x 13.50 x 7.22 in. (254 x 343 x 183 mm) |
| Cord Grips | Nylon, Stainless Steel & Nickel Options Available |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
